DD-XY-3000-2 is a high-performance spinning machine with integrated SC/CNC control, particularly suitable for the production of larger spun parts. The spinning machine with a multi-part machine bed guarantees a consistently high quality of the parts produced thanks to its moulded headstock and cross support. This machine can be used to produce a wide range of spun parts made from a wide variety of materials in many different shapes and contours.

As modern metalworking equipment, four-roller plate rolling machines offer the following core features: High-precision control Utilizing a hydraulic motor drive and PLC control system, they achieve precise displacement adjustment and automatic leveling, resulting in significantly superior rolling accuracy compared to three-roller models. Select models are equipped with sensors and a touchscreen for real-time monitoring of processing parameters. Versatile rolling capabilities Supports single-load pre-bending and fully automatic rolling to form the plate, eliminating the need for reversing. Capable of processing round, curved, tapered, and special-shaped workpieces, with a minimum rolling diameter of up to 50 mm. Combined drive systems for the upper and lower rollers and hydraulic cylinders on the side rollers enable complex deformation control. Efficient and energy-efficient design The servo motor and hydraulic system optimize oil flow and power transmission efficiency, reducing energy consumption while increasing processing speed. Structural Advantages The four-roller layout (upper and lower main drive rollers + auxiliary rollers on both sides) is more stable than three-roller models, reducing the risk of plate collapse. Equipped with upper and lower support devices, large-diameter workpieces can be rolled without additional support. Operational Convenience The fully automatic CNC system supports programmable operation, and some models feature a one-touch rolling function, significantly reducing the need for manual intervention. Note: Although the four-roller plate rolling machine is more expensive, its comprehensive advantages in processing range, precision, and efficiency make it the preferred choice for demanding applications.

1. The punching configuration save function allows you to simply call up the program when changing workpieces (significantly reducing debugging difficulty and time, and enhancing product consistency). 2. The support mechanism utilizes a pneumatic cylinder for strong support and minimal radial swing during workpiece rotation. 3. The flange width adjustment utilizes a stepped module for more stable flange width and time-saving adjustment. 4. The spindle is driven by a high-power servo motor and a precision planetary reducer, resulting in higher production efficiency and more consistent quality.

1. Pre-pressure relief technology helps prevent hydraulic shock and extend the life of pipes and seals. 2. High-quality hydraulic components ensure the stability of the hydraulic system. 3. All system components are easy to maintain and troubleshoot. The oil pump is bottom-mounted and uses positive pressure for suction. Filters, level gauges, and other components are equipped with alarms that automatically indicate faults. The hydraulic station is independent of the machine base, making it easy to maintain and away from heat sources. 4. The system is manufactured in strict accordance with international and industry standards, with optimal pipe curvature radii to minimize shock and vibration. 5. The system design focuses on energy conservation, minimizing power waste, and reducing heat sources. 6. High-precision suction and return oil filters ensure oil cleanliness. 7. Common faults and troubleshooting methods for the flanging machine hydraulic system are provided. 8. The hydraulic system is manufactured by a professional hydraulic manufacturer and in accordance with the national standard GB3766-83 to ensure manufacturing quality. 9. The fuel tank is shot-blasted, pickled, and surface-cleaned, then coated with an oil-resistant varnish to ensure cleanliness. An air filter and fine filter ensure effective oil filtration and ventilation. The system operates within a temperature range of 15°C to 65°C, controlled by an electric heater or cooler.

1. Core performance advantages ‌High one-time forming efficiency‌ Using the synergistic effect of the upper roller (steel roller) and the lower roller (elastic roller), the plate can be bent and formed by one pressurization, without the need for pre-bending process, significantly shortening the processing cycle, especially suitable for the continuous production of thin-walled pipes such as exhaust pipes14. ‌High precision and surface quality‌ The elastic layer of the lower roller is made of composite materials, with uniform stress distribution and small roller deflection, ensuring high geometric accuracy and smooth surface without scratches after forming, meeting the stringent requirements of exhaust pipes and other products for sealing and appearance14. ‌Dynamic adjustment capability‌ The upper and lower roller spacing and pressure are precisely adjusted through the PLC control system, combined with servo drive technology, which can adapt to the processing requirements of exhaust pipes of different diameters, and the processing process is highly stable46. 2. Structural design features ‌Optimized roller group configuration‌ The upper roller is a rigid steel roller, and the lower roller uses a steel roller core with an elastic layer (such as polyurethane) wrapped around it, which not only ensures the pressurization strength, but also avoids surface damage caused by metal contact, and improves the forming quality of the exhaust pipe46. ‌Automation Integration‌ Equipped with automatic loading, rolling and unloading functions, the whole process is automated through PLC control, reducing manual intervention and improving batch production efficiency45. III. Scope of application and limitations ‌Applicable scenarios‌ Mainly for metal sheets with a thickness of 0.5-6mm, especially good at processing carbon steel, stainless steel and aluminum plates with a yield strength of ≤350MPa, widely used in rapid prototyping of thin-walled cylindrical parts such as automobile exhaust pipes and ventilation ducts24. ‌Limitations‌ A single processing requires matching a specific upper roller mold, and the cost is relatively high when producing small batches and multiple specifications2; The maximum processing thickness is usually ≤10mm, which is not suitable for heavy plate processing28.

The core features of the two-roller plate rolling machine are mainly reflected in the following aspects: 1. Structural characteristics Simple and compact Adopting a two-roller structure (the upper roller is a steel roller, and the lower roller is a steel roller core with an elastic layer), the number of rollers is minimal, and the mechanical complexity is low; Elastic layer design The high elastic composite material of the lower roller makes the plate force uniform, reduces the roller deflection, and avoids surface scratches. 2. Production efficiency One-time forming No need to pre-bend the plate end, continuous bending and forming can be completed directly, shortening the processing cycle; High-speed processing The processing cycle of a single finished product can be shortened to 30 seconds, which is especially suitable for mass production of thin plates. 3. Processing accuracy No residual straight edge The plate is bent over the entire length, reducing the trimming process, and the finished product has accurate roundness; High dimensional stability Strict tolerance control, smooth and flat surface, suitable for high-precision parts (such as automobile exhaust pipes, thin-walled pipes, etc.). 4. Scope of application Applicable materials‌ Mostly used for rolling of metal thin plates such as carbon steel and aluminum plates (usually ≤6mm, carbon steel ≤5mm); Applicable fields‌ Covering automobile manufacturing, fire-fighting equipment, solar water heaters, ventilation ducts and other fields, especially suitable for small-diameter workpieces (diameter ≤1300mm). 5. Automation capability Intelligent control‌ Support PLC control of the whole machine operation, integrating automatic loading, rolling and unloading processes to reduce manual intervention; CNC compatibility‌ The operation interface is friendly and easy to integrate with the production line to realize CNC production. 6. Limitations Thickness limit‌: Not suitable for processing thick plates (generally carbon steel thickness >5mm); Poor adaptability to small batch production‌: The roller needs to be replaced frequently, affecting processing flexibility.

Features of Four-roller Plate Rolling Machine ‌1. High-precision forming‌ The four rollers work together to precisely control the curvature radius and shape of the plate, achieving a forming effect that is highly consistent with the design drawings18. ‌2. Small residual straight edge‌ The pre-bending function of the plate end significantly reduces the residual straight edge after processing and improves material utilization16. ‌3. Multi-function and strong adaptability‌ Supports rolling of round, arc, conical and special-shaped workpieces, and is suitable for plates of different thicknesses (as thin as metal sheets and as thick as alloy plates) and materials (carbon steel, stainless steel, aluminum alloy, etc.)46. ‌4. Automation and stability‌ Adopting PLC control, touch screen interface and hydraulic transmission technology, it realizes automatic leveling and displacement control, and the structure is sturdy and durable, with strong pressure resistance37. ‌5. High processing efficiency‌ The multi-roller continuous rolling design supports one-time pre-bending and rolling, reduces turning operations, and improves production efficiency

1. Equipment introduction: CNC spinning machine is manufactured by combining modern CNC technology and advanced processing and testing equipment. This spinning machine is designed for conventional products. After digital precision control, it can produce workpieces of various sizes and shapes through the spinning forming process to meet the personalized needs of customers. The workpiece replacement process is simple. You only need to install a new mold, call up the corresponding program, and perform precise calibration to quickly put it into production. The machine has undergone strict process flow and quality control, which can achieve high consistency in mass production and ensure that each product meets high quality standards. The equipment is easy to operate. Just start it with one button and manually load and unload the workpiece. In production applications, the surface of the processed products is smooth and the wall thickness is more uniform. It can significantly reduce material waste, improve product dimensional accuracy, smooth arc transition and accurate arc, and greatly reduce the labor of workers to ensure the safety of employees' operations.

Upper and lower rib flanging machine Equipment function: upper and lower inner flanging, upper and lower rib flanging

Equipment functions: flanging, punching, curling, pre-bending, pressing

Equipment function: This equipment integrates four core functions: flanging, flaring, punching and folding. It can accurately complete the complex surface processing requirements of carbon steel materials (folding thickness ≤ 4mm) and other metal materials. It is suitable for industrial scenarios such as pipe end processing and container sealing reinforcement.
