1. Equipment functions: flanging, secondary edge drawing, punching 2. Each station is driven by a servo motor for advance and retreat; 3. The molding configuration save function only requires calling out the program when changing the workpiece (greatly reducing the difficulty of debugging, saving debugging time, and enhancing the consistency of production products). 4. The spindle is equipped with a high-power servo motor and a planetary reducer to improve the punching efficiency and the accuracy of indexing. 5. This type of machine with an annual output of about 100 units can provide strong technical support. 6. The support device adopts a cylinder support, which has strong support force and small radial swing when the workpiece rotates. 7. The flange width adjustment adopts a step-type module, the flanging width is more stable, and the adjustment type saves time. 8. The corner type planetary reducer is adopted to make the machine lower and more convenient to operate.

Features of fan flanging machine: 1. Punching configuration saving function, only need to call out the program when changing workpiece (greatly reduces debugging difficulty, saves debugging time, and enhances the consistency of production products). 2. The spindle is equipped with high-power servo motor and star reducer to improve punching efficiency and indexing accuracy. 3. The flange width adjustment adopts step-type module, the flanging width is more stable, and the adjustment type saves time. 4. The corner star reducer is adopted to make the machine lower and more convenient to operate.

This equipment is specially developed for pipe flange flanging operations and is designed to meet the processing needs of small diameter and thick wall long pipes. Its significant advantage lies in its excellent flanging efficiency and easy operation, providing an efficient and convenient solution for related operations.

1. The forming configuration saving function only requires calling out the program when changing the workpiece (greatly reduces the difficulty of debugging, saves debugging time, and enhances the consistency of production products). 2. The spindle is equipped with a high-power servo motor and a star reducer to improve the punching efficiency and the accuracy of indexing. 3. The support device adopts a cylinder support, which has strong support force and small radial swing when the workpiece rotates. 4. The flange width adjustment adopts a step-type module, the flanging width is more stable, and the adjustment type saves time. 5. The corner star reducer is adopted to make the machine lower and more convenient to operate.

Features of flange flanging machine: 1. The pre-bending function is added during flanging to improve the yield rate when rolling stainless steel. 2. The main axis is equipped with a high-power servo motor and a star reducer to improve the punching efficiency and the accuracy of indexing. 3. The support device adopts a cylinder support, which has strong support force and small radial swing when the workpiece rotates. 4. The flange width adjustment adopts a step-type module, the flanging width is more stable, and the adjustment type saves time. 5. The corner star reducer is used to make the machine lower and more convenient to operate.

Equipment features: 1. Servo drives each motion axis, with high positioning accuracy and stable size 2. NC system control, through programming, can bend the bell mouth of various sizes 3. The program has a save function, changing the workpiece only requires changing the mold and calling the molding 4. One-button operation can easily complete the lower beading and upper bell mouth beading processes

1. The advancement and retreat of each workstation is driven by a servo motor; 2. With the molding configuration saving function, you only need to call up the program when replacing workpieces (greatly reducing the difficulty of debugging, saving debugging time, and enhancing the consistency of the production products). 3. Add pre-bending function when crimping to improve the yield when rolling stainless steel. 4. The spindle is equipped with a high-power servo motor and a star reducer to improve punching efficiency and indexing accuracy. 5. The flange width adjustment adopts a stepped module, the flanging width is more stable, and the adjustment method saves time. 6. The use of a corner-type star reducer makes the machine lower in height and more efficient in operation.

1. Full CNC control, only need to call the preset program to realize the edge spinning operation. 2. The precise control of the movement accuracy of each axis by the servo motor ensures high diameter accuracy and excellent consistency in product processing. 3. The equipment has a one-button start function and is easy to operate. Only one operator can easily manage two machines, thus significantly reducing labor costs and improving work efficiency. 4. After precision design and manufacturing, the head forming machine exhibits excellent performance in producing parts with precise dimensions and stable quality. This machine has the ability to achieve tight tolerances, ensuring every part meets established specifications. This high level of accuracy reduces error rates and significantly reduces the need for costly rework due to non-compliance with standards. 5. Improve production efficiency: With its excellent production efficiency, the head forming machine helps manufacturers achieve the manufacturing of large quantities of components in a short time. Its automated operation process and fast cycle operation mechanism greatly optimize productivity, thereby reducing manufacturing costs and shortening the production cycle. 6. Versatility and flexibility: The head forming machine can adapt to a variety of materials, including steel, aluminum, copper and various alloys. They can easily shape complex geometries such as heads, threads, flanges and collars. This versatility enables manufacturers to create custom components to meet specific requirements. 7. Save material and reduce waste: By leveraging the precise molding capabilities of these machines, manufacturers can minimize material waste. Efficient use of raw materials not only reduces costs but also promotes sustainability by minimizing environmental impact.

1. Full CNC control, only need to call the preset program to realize the edge spinning operation. 2. The precise control of the movement accuracy of each axis by the servo motor ensures high diameter accuracy and excellent consistency in product processing. 3. The equipped turning device can not only complete turning operations, but also has the ability to chamfer the workpiece. 4. In order to ensure the smooth installation and disassembly of the mold, the mold installation rack needs to be properly configured to improve operating efficiency and convenience. 5. Configure workpiece loading bracket 6. The equipment has a one-button start function and is easy to operate. Only one operator can easily manage two machines, thus significantly reducing labor costs and improving work efficiency.

1.Flanging machine is especially designed for the construction of axial fans body and for the construction of piping for ventilation. 2.It execute ribbing, flanging, punching and beading (stiffening of flange) on ferrule / duct. 3.Machine do all the working operations with only one positioning of piece. 4.Ferrule is clamped directly on the spindle through an expansion tool which is provided with interchangeable segments that can be easily manufactured. 5.Quick tool and segments change. 6.Cycle programming is very fast and simple. 7.Alignment of punched holes with laser projector.

Features: 1. With the punching configuration saving function, you only need to call up the program when replacing workpieces (greatly reducing the difficulty of debugging, saving debugging time, and enhancing the consistency of production products). 2. The supporting device is supported by an oil cylinder, which has strong support and small radial swing when the workpiece rotates. 3. The flange width adjustment adopts a stepped module, the flanging width is more stable, and the adjustment method saves time. 4. Spindle power is commonly driven by high-power servo motors and precision planetary reducers, which have higher production efficiency and more stable quality. This equipment has the functions of edge drawing, punching, curling and beading. Its features are as follows: 1. Punching configuration saving function, you only need to call up the corresponding program when changing workpieces. This design greatly reduces the difficulty of debugging, saves debugging time, and improves the consistency of production products. 2. The supporting device is supported by an oil cylinder, which has the advantage of strong supporting force and small radial swing when the workpiece rotates. This design makes the workpiece more stable during processing and improves production efficiency and quality. . 3. The flange width adjustment adopts a stepped module, which makes the flange width more stable and saves time in adjustment. This design makes the operation of the equipment more convenient and reduces the labor intensity of workers. 4. The spindle power is driven by a high-power servo motor and a precision planetary reducer, making the production efficiency higher and the quality more stable. This transmission method also has the advantages of high precision, good stability, and long service life.

1. The flanging wheel has rolling friction and is not easy to pattern. 1. The flanging flange is smooth and has no scratches: When selecting the flange, we should ensure that its surface is flat and has no scratches or dents. These defects may cause problems during use of the flange, such as leakage, uneven stress, etc. Therefore, when purchasing and storing flanges, special attention should be paid to their surface condition. 2. The supporting device is supported by an oil cylinder, which has strong supporting force and small radial swing when the workpiece rotates: the supporting device supported by the oil cylinder can provide strong supporting force, so that the radial swing of the workpiece is reduced when the workpiece rotates, thereby ensuring that the method The stability of orchid during processing. This type of support also improves the accuracy and consistency of the workpiece, allowing it to maintain good performance under a variety of working conditions. 3. The flange width adjustment adopts a stepped module, which makes the flanging width more stable and the adjustment saves time: The design of the stepped module makes the flanging width more stable and avoids errors caused by improper adjustment. At the same time, this design also greatly saves adjustment time and improves production efficiency. When replacing flanges of different widths, you only need to replace the corresponding stepped modules, which is very convenient and quick. 4. Rolling friction of the flanging wheel, not easy mode: During the flanging operation, the flanging wheel with rolling friction can reduce friction and avoid excessive heat generation that may deform the material. This design can reduce the wear and deformation of the workpiece and improve the accuracy and quality of the workpiece. At the same time, rolling friction can also reduce the difficulty and labor intensity of operation, making operation easier and more convenient.
